Multi-Colored Asian Lady Beetle

For nearly a hundred years the multi-colored Asian lady beetle, Harmonia axyridis has been used as a biological control agent. They are native to Asia from the Altai Mountains in the west to the Pacific coast in the east, and from southern Siberia in the north to southern China in the south. The first reported release of H. axyridis in the United States as a biological control species was in California in 1916. It wasn’t until 1988 that they were considered established within North America. There is speculation as to whether this establishment was from intentional release or from accidental occurrences. Many attempts to release this species as a biological control occurred after 1916 and each attempt seemed to have failed. With the discovery of an established population in 1988 the population of this species has spread exponentially. They now occur throughout most of the United States with exception to parts of the Southwest, Idaho, Montana and Wyoming.

 (Map taken from Bugguide.net)

The multi-colored Asian lady beetle is listed in the family Coccinellidae with other lady beetles. This species went through many name changes beginning as far back as 1773 when it was originally known as Coccinella axyridis. It wasn’t until 1915 that the name H. axyridis was finally decided on by Jacobson, and is still used today. There are nearly 475 species of Coccinellidae in North America, and we can now add H. axyridis to this number as it is now considered an established species.



Documentation of descriptions for H. axyridishas not changed since its first description during the 1960s. They vary greatly in coloration from red, orange-red, yellowish to black. They measure 0.19-0.32 inches with a width of 0.16-0.26 inches and are oval in shape. The wings may contain anywhere from 0 to 19 spots, which on the red, orange and yellow species will be black, and on the black species will be red. Coloration is weather dependent. The spots on their wings can actually be a winter weather gauge. Specimens with more spots would indicate a colder or longer winter. This allows the beetle time to produce more melanin to form more black spots. Black specimens are typically found in the western United States and all other color forms are found throughout the eastern United States east of the Rocky Mountains.

                                               (Photo taken from Wikicommons)

Likely the polymorphism of this species is inherited, each type passing on its own color to its offspring. Diet, temperature and other environmental influences may also contribute to color variations. No other species of lady beetle exhibits this type of polymorphism. This highly variable appearance can make identification difficult; therefore it may be necessary to use other key identification factors when identifying this species. In this species the characteristic to look for is a distinct “M” shape on the pronotum. Sometimes this mark may look more like two lines, or a series of four black spots. This species of lady beetles has more white on its pronotum than any other lady beetle species. All this variance in appearance has earned this species numerous common names including Halloween beetle, Harlequin ladybird, Japanese ladybug, Asian lady beetle, pumpkin ladybird, and the many-named ladybird.

The larval stage of this species goes through four distinct stages; egg, larval, pupae and adult. The larvae must go through four to five instars to reach adult size. There may be up to five generations per year depending upon region and temperature.

 (Photo taken from Wikicommons)

This species occasionally participates in cannibalism during the larval stage. Predominantly it is the eggs that are preyed upon by the larva. In large aggregations of aphid populations where H.axyridis eggs are laid the larvae of non-siblings feed on large amounts of eggs. In areas where aphid populations are reduced feeding on eggs or larvae provides necessary nutrients. However they seem to recognize fellow siblings and are most likely to feed on non-siblings. This practice affects overall population growth in a given area. It may affect populations as much as 16 percent in a given area.



Another factor affecting population growth is a bacterium in the genus Spiroplasma. This bacterium targets the male eggs which reduces the risk of cannibalism of females by siblings. The consumption of nonviable male eggs reduces the risk of starvation of female offspring by infected females. This behavior is so far not reported in North America, but instead is restricted to their native Asian range.

H. axyridis have a keen ability to track down aphid populations which is the main reason they are favored as biological control. The mating season of H.axyridis corresponds with peak aphid population growth. They must time oviposits with high densities of aphid populations in order to provide enough food sources for their offspring. Low populations of aphids would cause starvation of their offspring. There are indications that sight plays a huge role in larvae locating aphids. Larvae of H. axyridis will climb stems in search of aphids. Studies show that they hunt more frequently during daylight hours rather than nighttime. Females are able to detect aphids by smell from short distances which aid her in finding appropriate food sources for her offspring. Multi-colored Asian lady beetle larvae are voracious eaters and may consume up to 370 aphids during this stage. In their lifetime they may consume up to 4,000 aphids.



Even with their aposematic (warning) coloration and reflex bleeding of alkaloid secretions they still have enemies. Certain species of flies will lay their eggs within H. axyridis as will a parasitic braconid wasp called Dinocampus. These parasitic predators lay their eggs within the lady beetle. The resulting offspring will hatch and feed on the lady beetle from the inside. Once the wasp or fly larvae have reached full size they will pupate. Shortly thereafter the beetle will die. There are also numerous birds that will feed on these beetles as well as certain species of ants. Other lady beetles will also feed on H. axyridis but only if they are smaller. Spiders have also been reported to feed on H. axyridis when they are unfortunate to become ensnared in webs.



The introduction of H. axyridis to the United States was to provide biological control of aphid populations in a wide variety of crops. The first crops designated for release were pecan groves and red pines. Despite the intentional release into the environment during the early to mid-century it wasn’t until the late 1980s and early 1990s that establishment was realized.  They not only controlled aphids in pecans and red pines, they also moved to other areas and exhibited successful control of aphids in a wide variety of crops. These crops include apples, soybeans, citrus, sweet corn, hops, strawberries, peaches, cotton, alfalfa, winter wheat, and tobacco as well as many others.

 (Multi-Colored Asian Lady Beetle consuming Aphid)

For many years insect supply houses provided H. axyridis for purchase, but fewer supply houses are rearing them now because of the invasive implications now associated with this species. In the larval stage they are an effective control of aphids as well as scale insects in pine groves, this effectiveness comes from their inability to fly at this stage. The effectiveness of this species was questioned in the adult stage because of their ability to fly to other regions. In order to improve control in this species a flightless strain was created and released. This flightless specimen proved effective because of its inability to fly.

They are easy to rear in captivity and can be reared on a wide variety of aphids as well as numerous artificial diets making them excellent candidates for mass rearing and release projects.

Pesticides used to control insect pest populations have little adverse affects on H. axyridis except in the larval stage. Synthetic pyrethroids seem to affect H. axyridis less than it does aphids. The adult beetles are less affected by pesticides, fungicides and other chemicals in the environment than are the larvae. With constant changes being made in the pesticide industry and safer chemicals being developed all the time fewer H. axyridis are falling victim to chemical applications.

While it is true that H. axyridis is excellent at aphid control, as well as the control of other soft-bodied insects like thrips and scale insects, we must ask ourselves, at what cost? They are not particular about their diet and feed on a wide variety of insect prey including other lady beetle larvae. This can cause a serious decline in native species of coccinellids, and may potentially lead to several species being listed as imperiled. Nine-spotted lady beetles, Coccinella novemnotata are becoming increasingly more difficult to find in their native range. It is suspected that the much larger and more aggressive H. axyridis is at the very least partially responsible for this decline. In addition to native species falling prey to H. axyridis, they are also less able to compete for viable food sources against a much larger and voracious hunter. The result is less food to sustain the population of native species. Monarch butterfly eggs and young caterpillars have even fell victim to H. axyridis.

There is no question that H. axyridis is more than capable of providing excellent aphid control, but the cost may be considered too high. They not only feed on nuisance insects, they also feed on beneficial insects as well as insects that hold a worldwide appeal such as butterflies.  In addition, as with most exotic biological control species that become too abundant, they cause problems for humans. In the fall they form large aggregations on human dwellings, and other structures. This leads to many of these insects finding their way inside homes. It is not uncommon for these beetles to form aggregation populations in the hundreds of thousands. Persons sensitive to their presence have on occasion developed an allergic rhinoconjunctivitis as well as other allergies. As they fly around our homes and land on surfaces they leave behind frass which can trigger allergic responses in individuals that are sensitive, especially if they occur in large numbers.  Many people find it annoying to have these lady beetles accumulate inside their homes and fight an ongoing battle each fall to control their numbers. The secretions of these beetles stain furniture, floors and curtains. Many homeowners use toxic chemicals to kill the lady beetles, others are more tolerant and remove the lady beetles by vacuuming them up and moving them back outside. This species is reported to give off a musky odor when disturbed and may inflict a minor bite. Not only is it homes that face invasion, so do beehives. Beekeepers reportedly fight to keep these lady beetles out of hive boxes. They appear to cause no harm to the bees themselves, but are a nuisance to the beekeeper.


H. axyridis is one of just a few species of lady beetles that form large aggregations in the fall. In their native range of Asia they are known to orient themselves to visual landmarks on the horizon. Often these areas are mountains or large rocky hillsides.  They will use these sights to hide within cracks and crevices to wait out winter’s icy blast. In the United States they incorporate this same orientating technique and often “home” in on our houses and other structures. There are reports of these beetles making their way into hospital operating rooms and into institutes with bio-containment facilities. These are areas with zero tolerance policies in place for possible biological invasion of outside pests. They have also been reported to contaminate food processing plants, making their way into food being processed for human consumption. This destroys large lots of food costing significant financial losses to those companies. It is believed they are more widely attracted to buildings at higher elevations. They are also reported to aggregate on mountain ranges such as the Smoky Mountains. They are also attracted to light colored structures, such as white, tan, yellow, etc. However, this does not mean they won’t be found on other buildings as well.

  These beetles will hibernate, or enter into a type of diapause beginning about November and ending in March. They are not looking for places to stay warm, as most places where they spend the winter months are not heated. They instead are waiting for winter to end and warm weather to return so their food source will once again be plentiful. They seek areas that protect them from exposure to the outside weather. I’ve found them in basement window wells, behind the bark of trees, and under rocks. H.axyridisuse pheromone cues to signal to others of their kind that a suitable location has been found. It is these chemical cues that lead to such large numbers of lady beetles accumulating in a given area. They may also smell feces left behind by previous aggregations of Harmoniasindicating that the location is suitable. They prefer areas that are cool with little to no light. Basements or attics are perfect overwintering areas for these beetles. Occasionally during the winter we have a warming of weather, on these days H. axyridis will become active and seek out warmth. It is not uncommon to find them flying into light fixtures or towards windows. This warming of temperatures seems to trigger a chemical response in the beetle that signals them to wake up and become active again. As soon as the temperature drops again however they will once again become dormant. The biggest problem comes in the autumn and spring when the beetles are moving in or out of structures. It is at this time that human contact is the highest and most aggravating.

 Besides using harsh insecticides to keep these lady beetles out of our homes, the use of DEET and camphor have been used successfully as a deterrent and are much safer alternatives. The beetles find these odors offensive and will avoid areas that are sprayed with these chemicals. One drawback to using DEET is its ability to dissolve paint. Therefore it must be applied to surfaces that will not suffer from its application. There are DEET strips that can be purchased and used and would be a less expensive way to repel these beetles. ⁴ While the large aggregation of these beetles is no doubt annoying and bothersome, killing them outright may not be the best solution depending upon your viewpoint. If you are a gardener or farmer you may appreciate the biological control of aphids they provide, even if you temporarily forget their importance when trying to keep them out of your home. On the other hand if you prefer native species of lady beetles and are opposed to the much more aggressive newcomer displacing our own lady beetles you may feel differently and have no love for these beetles.
H. axyridis sets itself apart as one of the few lady beetles that will feed on substances other than aphids and soft bodied insects. They will also form aggregations in fruit orchards and gather on the ripening fruit. It has been reported they will feed on apples, pears and grapes thus ruining the fruit meant for human consumption. Vineyards suffer the highest economic impact of the H.axyridis. The beetles are next to impossible to remove from the grape clusters, so many are crushed along with the grapes. The result of this insect contamination is tainted wine with a foul flavor that cannot be consumed. All of these negative impacts of the beetle can cause significant economical losses to fruit growers, homeowners and consumers. More research needs to be done to quantify the annual financial impacts this species is causing to the environment, orchards, and croplands.

 Ongoing research is being done to further understand the potential impact H. axyridis will have on all native species of coccinellids. Cornell University is a driving force in the research being done on this species. They currently have a citizen science project underway that involves persons from North America. They request that people head outside and photograph lady beetles. Submit your photos, along with data to their website and all information is processed to better understand the impact that H. axyridis is having on the environment. Their website www.lostladybug.org is instrumental in raising awareness of the plight of native lady beetles, and in providing information on H. axyridis.

Exactly why they were imported into the United States for release, beyond the obvious aphid control, is unclear. Apparently persons in the agricultural industry felt the need for a more aggressive aphid predator than our native species. Many attempts to introduce this species into nut groves, pine groves, orchards, croplands and other areas of commerce failed. This continuation of failures did not stop efforts to try and establish this species. One has to wonder if at any time was it seriously questioned the appropriateness of continuing with further releases. It wasn’t until the late 1980’s that an established population was discovered. From this original colony the spread of this species ran rampant. Currently it is found throughout most of North America in large numbers. In Missouri where I live it is the most commonly seen lady beetle. The only other species I find on a regular basis are the convergent lady beetle (Hippodamia convergens) and the pink-spotted lady beetle (Coleomegilla maculate), and their numbers are much lower than in years past. Over the course of a personal 6 year study I’ve found a significant decrease in native species and a large increase in H. axyridis.

In conclusion this species should be considered neither beneficial nor harmful. They provide excellent control of harmful insects such as aphids and scale insects. Their large numbers gives them an advantage in the consumption of large numbers of these harmful insects. On the flip side their prolific breeding and large populations are potentially causing the demise of our own native species of lady beetles. The formation of large aggregations can be an annoyance to humans and potentially cause health problems. Their association with orchards and other fruit crops can lead to destruction of food. To say the good outweighs the bad, or vice versa, would be difficult without further research. I believe it will take time to discover the final verdict on this species.



References:

1   1.)  Role of Visual Contrast in the Alighting Behavior of Harmonia axyridis

(Coleoptera: Coccinellidae) at Overwintering Sites

C. A. NALEPA,1 G. G. KENNEDY,2 AND C. BROWNIE3
2.) The multicolored Asian lady beetle, Harmonia axyridis: A review of its biology, uses in biological control, and non-target impacts R L Koch

3.) The multicolored Asian lady beetle, Harmonia axyridis: A review of its biology, uses in biological control, and non-target impacts R L Koch

4.) www.bugguide.net (http://www.europe-aliens.org/speciesFactsheet.do?speciesId=50711)

5.) http://www.europe-aliens.org/speciesFactsheet.do?speciesId=50711
6.) http://en.wikipedia.org/wiki/Harmonia_axyridis
7.) http://www.ncbi.nlm.nih.gov/pmc/articles/PMC524671/
8.) http://edis.ifas.ufl.edu/in361
9.) www.entomology.ksu.edu/DesktopModules/ViewDocument.aspx?...4521
10.)linkinghub.elsevier.com/retrieve/pii/S0022201106002199
11.) www.lostladybug.org

Fishing Spider

This beautifully patterned spider is a Fishing Spider in the family Dolomedes. They earn their name fishing spider from their preferred habitat near water. They are often seen along the shore of lakes and ponds where they rest their front legs on the surface of the water waiting for vibrations that will alert them to possible prey nearby. They are able to dart out across the water and grab unsuspecting aquatic insects. Some reports indicate that they may also capture small fish when the opportunity arises.

It is not uncommon to find these spiders quite a distance from water, in fact, the species pictured here is more commonly associated with moist woodland areas where they climb trees. Their color provides perfect camouflage against the bark of various trees. They are also found in homes upon occasion. I have one that currently lives in our basement. I've given her the name Sadie and actually find myself looking for her when I do laundry. I prefer to co-exist with this gorgeous beast and appreciate the hard work she is doing in the form of insect control than to kill her needlessly.

These are a large spider that somewhat resemble Wolf spiders. In fact many people who encounter these spiders mistake them for wolf spiders. They may reach legspans up to 4 inches, which is quite large for a spider. Average body length varies from 15 to 26 millimeters....males are smaller at 7 to 13 millimeters. They are brownish-gray with lighter brown and black markings. Some specimens have a pinkish tint on their abdomen. The legs are banded black and brown.

Mating takes place in spring soon after hibernation. The female will form an egg sac sometime in June that she will carry with her. This maternal care helps guarantee that the spiderlings will hatch and get the best start possible free from predation. Egg sacs may contain up to 1000 individual spiderlings and hatch sometime between July and September. The young spiders will overwinter under the bark of trees, under logs, or rocks or in leaf litter. When spring arrives the cycle starts over.

While these spiders are large they are not aggressive. They are more likely to flee than stand their ground. Bites typically occur when they are mishandled. The bite is no more severe than a bee sting, however if you are allergic to bee venom or spider venom possible serious reactions can occur.

A new stream -- and possibly a new Strong-case maker: Psilotreta frontalis

This morning, my friend with all sorts of connections -- ahem! -- got us invited to look at a new stream at Montfair Resort Farm (http://www.montfairresortfarm.com/) a beautiful place to vacation and hike in the hills above the Doyles River.   We had a number of streams from which we could choose, so we hiked down to a small one -- remote -- that empties into a pond.

This turned out to be a very small stream, low water at the moment, and there were not a whole lot of riffles.  Still, we saw plenty of insects including what for me would be a new Stong-case maker species, Psilotreta frontalis.  I'm not 100% sure of this ID, but let me lay out the evidence, such as it is,  using Beaty's "The Trichoptera of North Carolina," p. 97.

P. frontalis -- larvae up to 14 mm; coloration variable, generally a broad black stripe extending dorsally over head, sometimes wider than frontoclypeus; two light areas anteromedial to eyes extending to anterolateral corners of frontoclypeus in all but darkest specimens; dark on pro- and mesonotum confined to middle stripes and lateral edge; pronotum with anterior edge slightly darker than ground color; anterolateral pronotal projections relatively short.  Spring fed streams in Sandhills and Mountains.

We need a close-up of the head, pronotum, and mesonotum which I've tried to produce in the following photo.

1. There clearly is a broad black stripe extending over the head, and it is indeed wider than the frontoclypeus in places.

2. I really don't know about the pale areas anteromedial to the eyes.  That's where I need to do further work.

3. We can see that there are black stripes on the pro- and mesonotum in the middle and on the sides.

4. No question that the anterior edge of the pronotum is darker than the ground color.

5. And, I think the anterolateral projections on the pronotum are shorter than those that I normally see.

Compare:

a. today's larva

b. what I normally see, which I think is Psilotreta labida

So a tentative conclusion on this: the Strong-case makers that I saw today might be Psilotreta frontalis.  Whatever they were, there were a lot of them!

________________

As for the rest...

1. Flatheaded mayfly, Maccaffertium merririvulanum, one of the two species we normally see in small head-water streams.  Note the pale "V" marks on segments 7-9.

2. And the other flathead that we commonly see with M. merririvulanum -- Maccaffertium pudicum.

3. A tiny pronggilled mayfly, genus Paraleptophlebia

4. And a Saddle-case maker -- Glossosoma nigrior.

Saddle-case makers, because their cases are open at both ends, can reverse direction inside of their cases, with their heads sticking out at the top and then at the bottom.  Right after I took this photo, this larva ducked back into the case -- and then it popped its head out the bottom.

And then it went back to the top!

5. Oh, there were also quite a few Roach-like stoneflies around -- clearly genus Tallaperla.

________________

Looking forward to returning to Montfair soon to get into more of their streams.

Large winters/Small winters: how to recognize them when they're small

They're are a lot of people sampling streams at the moment as the fall sampling season comes to its close.  If you're out there, and you live in our part of the country, there's a good chance you'll be seeing tiny, large winter stoneflies (genus, Taeniopteryx) and small winter stoneflies (genus Allocapnia).    Your monitors will probably urge you to keep them for identification back at the lab.
But, it's actually fairly easy to ID them right in the field for those of you urged to do family level ID.

That's a large winter stonefly in the photo at the top of the page.  The photo was taken on 10/27 last year.   Clearly, it looks nothing like the large winter stonefly pictured in Voshell's Freshwater Invertebrates, p. 134.  He's showing you what they will look like when they're mature.  More like this.

But you can probably ID these large winters right in the field with a loupe, even at this time of year.

Look for 4 things.  1)  These nymphs are "freckled," "spotted," the colors range from gray (very small)  to reddish brown (somewhat larger); 2) The bases of the antennae are unusually thick; 3) There's a pale , medial stripe running from the head to the tails; And 4) to really be sure that this is a Taeniopteryx large winter stonefly, flip it over and look for "coxal gills."

They look like bean sprouts, and they're very large on the very smallest of nymphs.
________________

Small winter stoneflies.  They always show up towards the end of October.

And there are two ways to recognize them.  1) When they're small, they're virtually transparent.  When I put them into my petri dish to take a picture, I sometimes have trouble making out where they are.  And 2) they're "floaters."  Maybe they're just too light to sink!  They always seem stay on top of the water when put into a tray.

This feature is commonly seen even with larger nymphs -- even when they're mature.

________________

Good luck!

Imperial Moth

Imperial Moths (Eacles imperialis) in the family Saturniidae are large silk moths commonly found in forested areas throughout Missouri. They are also often found in suburban areas, especially near lights at night. The biggest one I ever found was at a gas station/convenient mart on the outskirts of St. Joseph.
Their range includes most of the Eastern United States from Nebraska to Maine. There are some reports that they are declining at an alarming rate in the northeastern part of their range. The population decline in these locations could and probably is due to habitat loss. Throughout the rest of their range their numbers are secure to abundant. The adults are large with wingspans up to 5.5 inches and are yellow with variable lavender spots. Males are smaller than females.

These large moths do not feed as adults, instead they get all the nutrition they need as caterpillars. If you've never seen one of these in their larval form, it is truly impressive. When hatched they are barely visible and possess an incredible appetite. They feed voraciously and reach lengths up to 3 or 4 inches when ready to pupate. They manage this in the span of several weeks.  It has been said that if a human baby gained weight like a caterpillar, they would weigh as much as a hippo in a single weekend. They feed on a wide variety of tree species like oak, hickory, walnut, pine, maple (including box elder), Norway spruce, sassafras, sweet gum and many others.

Moths are covered in furry scales that protect them from cooler nighttime temperatures. These large moths take it to a whole new level with what appears to be a winter-weight coat, complete with scarf and leg warmers. After midnight the females will begin signalling for males by emitting a pheromone. The males are capable of "smelling" the females from distances of more than a mile. He uses his large, feathery antennae to home in on her scent. Females will lay eggs one at a time, or up to 2 to 5 on the leaves of host plants. Eggs hatch in a couple of weeks. When ready to pupate they will move to the base of the host tree and burrow into the ground to pupate for the winter.

Naturalist Gene Stratton Porter wrote about the Imperial Moth in her novel "A Girl of the Limberlost" It was a prominent character in the plot development of the novel. She had a life long love of silk moths and shared her passion for their beauty in the book Moths of the Limberlost.

Make that Goera fuscula: my mistake

When I was at the point of posting yesterday's entry I had second thoughts and almost hit "delete" instead of "publish."  I should have.  After closer study this morning, I've determined that the Goerids I found yesterday were, species, Goera fuscula, not Goera calcarata.

The thing that bothered me yesterday -- that drove me to look at these insects again -- was the size. The larva that I examined was 11 mm: Beaty has "8-9 mm" for G. calcarata, but "9-11mm" for G. fuscula.  So let's have a look at Beaty's description of G. fuscula.

G. fuscula -- larvae 9-11 mm; 4 pairs of sclerites on metanotum; sternal thoracic plates distinct; face with central area smooth; posterior carina sharp and high.  Mountains only. Rare with less that 15 BAU records.  (Beaty, "The Trichoptera of North Carolina," p. 87)

1.  As I've already noted, the larva that I pulled from its case and measured was 11 mm; the case was 12 mm.

2. There are indeed 4 pairs of sclerites on the metanotum, not 3!  If you look directly down on the dorsum of the metanotum you'll only see three, but if you turn the larva on its side, you'll then see the 4th.  (Sclerites are bounded, dark spots on the fleshy body, normally containing setae.)

3. And yes, the sternal thoracic plates are distinct.  That's the first thing I noted this morning.  That on its own eliminates G. calcarata for the ID.

4. Head/face -- it's flat, almost depressed, surrounded by a quite clear carina.

Another look at the carina and head/face in a photo from my friend in Sugar Hollow.

Goera fuscula.  The tolerance value remains undetermined since it's an uncommon species.

________________

One other point of interest on Goera in general.  On Friday, when my friend and I went to that small stream in Sugar Hollow, she saw some cases that looked like Goera.  They appeared to be sealed off for pupation, but she took them home for a look.  After a time, the larvae emerged -- the cases weren't sealed off at all!

The same thing happened to me yesterday.  Here's what I saw.

I was initially disappointed since I knew by the cases that these were Goerids: but then they emerged.

When I was reading Glenn Wiggins (Larvae of the North American Caddisfly Genera, 2nd edition, 1996) on the Goerids, I discovered that this is characteristic of the Goerids.  Look at this photo from my friend's collection, then I'll quote from his book.

"Larvae of the Goeridae are characterized by major modifications to the thoracic nota.  The pronotum is enlarged and thickened laterally; sclerotized plates of the mesonotum are subdivided into two or three pairs of smaller sclerites, and the mesepisternum is extended anterad as a prominent process.  These modifications are integrated to form a set of close-fitting sclerites forming an operculum that closes off the anterior opening of the case when the larva withdraws."(Wiggins, p. 226)

So, if you find one of these cases and it appears to be sealed -- don't be too sure!

Goeridae -- the "Weighted-case Maker" -- at South River: Goera calcarata

(Please read the next entry.  This ID was wrong.  The larvae I found were G. fuscula.)

I've been waiting a long time to see this one -- but it's not really that photogenic!  This is the first Goerid (Weighted-case maker) I've seen, and I had to go to the South River (Greene County) to find it, that despite the fact that my friend has found them in a regular way in the small streams in Sugar Hollow.

At first glance, Goerids look a lot like Uenoids, but one of the ways in which they differ is in the design of the case.  "Case: Similar to that of Neophylax [Uenoid] but with a continuous row of larger ballast stones laterally, usually two."  (Beaty, "The Trichoptera of North Carolina," p. 87)  Uenoids typically have 3 stones on each side of the case, in some cases 4.

But what really sets the Goerid apart is the pronotum: "pronotum produced anterolaterally into wide, sharply pointed processes."  (Beaty, p. 87)  This is the best I could do in a live view.

They're easier to see in this microscope view as is the pointed nature of the head.

Another view  -- live view -- of the pronotal and mesonotal projections taken by my friend in Sugar Hollow.

According to Ames (Caddisflies, p. 232) the most common Weighted-case maker we see is Goera calcarata, and that's the species I found.   Beaty describes G. calcarata in the following way:

G. calcarata -- larvae 8-9 mm; 3 pairs of sclerites on metanotum; pronotum with central raised area the anterior margin with conspicuous spicules; sternal thoracic plates indistinct.  Common in the Mountains and Sandhills.  In North Carolina, G. calcarata is given a TV of 1.0.

Of the features noted by Beaty, the "3 pairs of sclerites on the metanotum" were very clear.

I could see the raised area on the prontum, but my photo is not very good.

I could not see any plates on the thorax.  But in the end, the metanotal sclerites will do to establish the identification since the other species that are found in NC (G. fuscula and G. stylata) both have 4 pairs of sclerites, not 3.   This larva was 11 mm.

Goera is known to fly fishermen as the "Little gray sedge," and according to Ames (p. 232) "They appear through June in the mid-South and into August in the Adirondacks and New England."

Nice to finally add this to my list.

________________

Other photos:

1. Odontocerids (Strong-case makers) -- Psilotreta labida.  They were easy to spot on the rocks.

2. A pretty, small minnow mayfly -- Acentrella turbida.  Fully mature.

3. And -- finally -- the first small winter stoneflies of the new season.

Not much to look at at this stage of the game.
________________

All Goerids were found in Entry Run, a tributary of South River.
